| Quantity: | |
|---|---|
| Engine | / | YB804 | Lifting power | kN | 12.3 |
| Model | / | 4L-4105T | Three-point suspension type | / | Category 1 or 2 |
| Horsepower | HP | 80 | Hydraulic output flow | L/min | 34 |
| Displacement | L | 4.085 | Number of multi-way valves | / | 2 |
| Torque | NM | ≥280 | Length*Width* Height | mm | 4256X1786x2877 |
| Gearshift | / | 12+12 | Wheelbase | mm | 2070 |
| Technical route | / | Synchronizer shift | Ground clearance | mm | 325 |
| Speed range | km/h | 2.13-37.61 1.97-32.3 | Turning radius | m | 3.2+0.3 3.3±0.2 |
| PTO speed | r/min | 540/1000 | Weight | kg | 3240 |
| Tire size | / | 9.5-24/14.9-30 | |||
