| Quantity: | |
|---|---|
| Engine | / | YB1104 | Lifting power | kN | 20 |
| Model | / | HF Power 4R | Three-point suspension type | / | Category 1 or 2 |
| Horsepower | HP | 110 | Hydraulic output flow | L/min | 58 |
| Displacement | L | 4.67 | Number of multi-way valves | / | 2or 3 |
| Torque | NM | ≥490 | Length*Width* Height | mm | 4530x2150x2900 |
| Gearshift | / | 16+8 | Wheelbase | mm | 2405 |
| Technical route | / | Synchronizer shift | Ground clearance | mm | 405 |
| Speed range | km/h | 1.77-34.8 | Turning radius | m | 4.9±0.3 |
| PTO speed | r/min | 540/1000 | Weight | kg | 4200 |
| Tire size | / | 12.4-26/16.9-34 | |||
