| Quantity: | |
|---|---|
| Engine | / | YB504 | Lifting power | kN | 9.1 |
| Model | / | 4L-495 | Three-point suspension type | / | Category 1 |
| Horsepower | HP | 50 | Hydraulic output flow | L/min | 32 |
| Displacement | L | 2.98 | Number of multi-way valves | / | 2 |
| Torque | NM | ≥180 | Length*Width* Height | mm | 4136X1670x2807 |
| Gearshift | / | 12+12 | Wheelbase | mm | 1990 |
| Technical route | / | Shuttle synchronizer shift | Ground clearance | mm | 310 |
| Speed range | km/h | 2.37-38.46 | Turning radius | m | 3.8±0.3 3.3±0.2 |
| PTO speed | r/min | 540/1000 | Weight | kg | 2490 |
| Tire size | / | 7.5-16/12.4-26 | |||
