| Quantity: | |
|---|---|
| Engine | / | YB604 | Lifting power | kN | 6.35 |
| Model | / | 4L-4102 | Three-point suspension type | / | Category 1 |
| Horsepower | HP | 60 | Hydraulic output flow | L/min | 32 |
| Displacement | L | 3.857 | Number of multi-way valves | / | 2 |
| Torque | NM | ≥225 | Length*Width* Height | mm | 4186X1730X2854 |
| Gearshift | / | 12+12 | Wheelbase | mm | 2040 |
| Technical route | / | Shuttle synchronizer shift | Ground clearance | mm | 310 |
| Speed range | km/h | 2.27-39.36 1.97-32.3 | Turning radius | m | 3.8±0.3 3.3±0.2 |
| PTO speed | r/min | 540/1000 | Weight | kg | 2780 |
| Tire size | / | 8.3-20/14.9-28 | |||
