| Engine | / | YB654 | Lifting power | kN | 10.3 |
| Model | / | 4L-4102 | Three-point suspension type | / | Category 1 or 2 |
| Horsepower | HP | 65 | Hydraulic output flow | L/min | 34 |
| Displacement | L | 3.857 | Number of multi-way valves | / | 2 |
| Torque | NM | ≥245 | Length*Width* Height | mm | 4136x1670x2807 |
| Gearshift | / | 12+12 | Wheelbase | mm | 1990 |
| Technical route | / | Shuttle synchronizer shift | Ground clearance | mm | 325 |
| Speed range | km/h | 2.17-36.45 | Turning radius | m | 3.2±0.3 3.3±0.2 |
| PTO speed | r/min | 540/1000 | Weight | kg | 2400 |
| Tire size | / | 8.3-24/11-32 7.5-16/12.4-26 | |||
