| Quantity: | |
|---|---|
| Name | / | DF-221/22L | Wheel Tread | mm | 800/740/640/580 |
| Structural Weight | kg | 530 | Min. Ground Clearance | mm | 185 |
| Overall Dimensions | mm | 2680 x1060x 1250 | Engine Model | / | ZS1115 ZS1115N |
| Tire size | / | 6.00-12 | Rated Power | hp/kw | 22/16.06 |
| Driving Speed | km/h | F:1.4~16.5 R:1.1~4.3 | Rotary Tiller Wdth | mm | 100 |
| Gear NO. | / | Forward F6 Reverse R2 | Rotation Speed Of Shaft | rpm | 188/300 |
| Blades NO. | / | 28 | |||
